RadioDoctor motorola gm300 programming software be downloaded by joining theand the. There are many more settings motorola gm300 programming software this software such as adjusting power for each channel. Dell E5500 w native com port, tried DOSBox, boot to DOS, etc. If you have an older model computer, you are probably in luck.
The Motorola GM300 can be re-programmed quite easily to allow use on our Amateur Radio bands. The radio is made in both a VHF and UHF versions, and makes an excellent 2mtr or 70cms mobile/base station radio.
Most of the radio's I have worked on have originally been 8 channel units. These can be modified to operate on 16 channels quite easily.
The programming interface can be made for a low cost. All it consists of is a RS232 to TTL level converter, that connects between the serial port of your PC and the radio's microphone socket.
Amateur Radio Conversion.
The radio requires the Motorola Software which can be found if you ask around or search for it on the FTP sites on the Internet. If you can't find it then try your local Motorola dealer who should be able to help at a small cost.
You also have to make an interface, or purchase one.
Motorola Radius Gm300 Radio Doctor
To program the radio onto the Amateur band, you can find some versions of software that have been hacked into allowing frequencies to be entered to bring the radio into the amateur bands which normally are just bellow the original working frequency. However this depends on your version of software, if it's a un-hacked version then you have to press the
16 Channel conversion. (for 8 channel radio's only)
To program the radio for 16 channels all you need to do is edit a file called GM300.MDF. You do this with the help of a Hex editor such as Hex Workshop. The file you need to modify is called GM300.MDF and can be found in the main directory of the Motorola software. Keep a backup of your original GM300.MDF file, just in case you make a mistake.
I have made a small video that shows the Hex Workshop screen during the modification. This should help you understand the procedure of editing the file which when complete will give you 16 channels. Click below to download.
Procedure
- Get a copy of Hex Workshop
- Start the Hex Workshop program and open the file GP300.MDF to begin editing.
- Go to 'Tools', and the 'Generate Checksum'.
- Make sure 'Entire Document' and also 'Decimal' are ticked. Then press 'Generate'.
- Look in the 'Checksum-16' box, in my version of software for example this results in a checksum of 5514. (yours may be a different number depending on the version of Motorola software)
- Write this number down, as you need it later.
- Press 'Cancel' to return to the main window and your next step.
- Go to 'Edit' and then 'Find'. A pop-up window appears.
- You need to enter the model number of your radio. For e.g. M34GMC00D3AA.
- When you enter the model number leave off the last two letters(AB on my radio).Make sure 'ASCII' is ticked.
- When you press 'Find Next', you will see your model number highlighted.
- If you count 8 numbers after the highlighted section, you should see the number '08' as long your radio is originally a 8 channel set.
- Edit the '08' to '10' (note 10 in Hex is equal to 16 in decimal).
- You now need to edit the start of the program, to allow the software to run.
- In the first few lines look for a Hex number that you can easily take away 8 from.
- In my software at address 00000040 you will see the number '78' on the right.
- Edit this to be '70'.
- Now you must do a final checksum and make sure it equals the original value.
- If this is the same, then replace you original file with the modified file.
- Try to reprogram your radio with the extra 8 channels to give you 16 channels.
Hi there. I have a Motorola GM300 that I've been trying to reprogram for a while. The radio looks brand new witch has nothing programmed into it, it has never been used. I've downloaded several GM300 programming files none of them have worked the software can't read the radio. I'm assuming that MS-DOS versions won't work for the GM300 that I have however I've not found any windows versions of the software.Motorola Gm300 Radio Doctor Download
I came across something in yahoo called Radio Doctor witch is Windows based and apparently runs under XP on a modern computer and it allows you to add more channels to the radio. I've not managed to find any download links for this fantastic software or any further info in regards to where to find the software.I understand this radio can go up to 40 channels witch is ideal for Amateur use on 70cm witch I plan on using this radio for as a back up radio.
I'm really confused as to why none of the GM300 DOS based software will read the codeplug? Do I need to change some jumpers on the radio perhaps?
